Edwards nXRi Multi-Stage Roots Vacuum Pumps

Representative Image

Edwards nXRi Multi-Stage Roots Vacuum Pumps 1

Edwards nXRi Multi-Stage Roots Vacuum Pumps 2

Edwards nXRi Multi-Stage Roots Vacuum Pumps 3

Edwards nXRi Multi-Stage Roots Vacuum Pumps 4

Edwards nXRi Multi-Stage Roots Vacuum Pumps

The nXRi high performance, compact dry pump delivers unrivaled pumping speeds in the most compact package, with easy integration into new or existing vacuum systems. The nXRi's lower input power and zero maintenance create real performance improvements and cost benefits across a range of applications.

Dimensional Drawings

Edwards nXRi Multi-Stage Roots Vacuum Pumpsdrawing

Charts

Edwards nXRi Multi-Stage Roots Vacuum Pumpschart

Videos

Edwards Presents nXRi High Performance Compact Dry Vacuum Pump

Edwards has revolutionised the vacuum pump market with the new nXRi high performance, compact dry pump. It delivers unrivalled pumping speeds in the most compact package.

Runtime: 2:29

Specifications Table

Pump Model	nXR30i	nXR40i	nXR60i	nXR90i	nXR120i
Pumping Speeds	50 (Hz) 18.0 CFM 500 L/min 8.00 L/s 30.0 m3/hr 60 (Hz) 18.0 CFM 500 L/min 8.00 L/s 30.0 m3/hr	50 (Hz) 24.0 CFM 667 L/min 11.0 L/s 40.0 m3/hr 60 (Hz) 24.0 CFM 667 L/min 11.0 L/s 40.0 m3/hr	50 (Hz) 35.3 CFM 1000 L/min 16.7 L/s 60.0 m3/hr 60 (Hz) 35.3 CFM 1000 L/min 16.7 L/s 60.0 m3/hr	50 (Hz) 53.0 CFM 1500 L/min 25.0 L/s 90.0 m3/hr 60 (Hz) 53.0 CFM 1500 L/min 25.0 L/s 90.0 m3/hr	50 (Hz) 71.0 CFM 2000 L/min 33.0 L/s 120 m3/hr 60 (Hz) 71.0 CFM 2000 L/min 33.0 L/s 120 m3/hr
Ultimate Pressure	Total Without Gas Ballast 3.00 x 10^-2 hPA 3.00 x 10^-2 mbar 3.00 Pa 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 hPA 3.00 x 10^-2 mbar 3.00 Pa 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 hPA 3.00 x 10^-2 mbar 3.00 Pa 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 hPA 3.00 x 10^-2 mbar 3.00 Pa 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 hPA 3.00 x 10^-2 mbar 3.00 Pa 2.25 x 10^-2 Torr
Cooling Method(s)	Method Convection	Method Convection	Method Convection	Method Convection	Method Convection
Motor Power HP (kW)	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )
Inlet Flange	KF25	KF25	KF40	KF40	KF40
Exhaust Flange	KF25	KF25	KF25	KF25	KF25
Noise db(A)	55.0	55.0	55.0	55.0	55.0
Weight Lbs (kg)	60.0 ( 27.0 )	60.0 ( 27.0 )	64.0 ( 29.0 )	64.0 ( 29.0 )	64.0 ( 29.0 )
Dimensions in. (mm.)	18.8 x 8.60 x 12.0 (478 x 217 x 301 )	19.5 x 8.60 x 12.0 (478 x 217 x 301 )	19.5 x 8.60 x 12.0 (494 x 217 x 301 )	19.5 x 8.60 x 12.0 (494 x 217 x 301 )	19.5 x 8.60 x 12.0 (494 x 217 x 301 )
Lubrication Type	Dry	Dry	Dry	Dry	Dry
Technology Type	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots

X CLOSE

Got VacuCAD^SM?

VacuCAD is a free library containing thousands of 2D CAD drawings (in DXF format) and 3D Models (in STP format) for many of our standard vacuum components and chambers. Please Log in

Ordering Table

(Click column headers to sort data)

X CLOSE

Pump Model	Inlet Flange	Voltage & Phases	Manual	Description	Part Number	Price	In Stock	Add To Cart
Pump Model	Inlet Flange	Voltage & Phases	Manual	Description	Part Number	Price	In Stock	Add To Cart
nXR30i	KF25	100-127/200-240V 50/60 Hz, 1- Ø		EDWARDS nXR30I MULTI STAGE ROOTS DRY PUMP, KF25 INLET FLANGE, 30 M^3/HR, 100-127/200-240V, 50/60 HZ, 1-PHASE	A90301983	P.O.R.
nXR40i	KF25	100-127/200-240V 50/60 Hz, 1- Ø		EDWARDS nXR40i MULTI STAGE ROOTS DRY PUMP, KF25 INLET FLANGE, 40 M^3/HR, 100-127/200-240V, 50/60 HZ, 1-PHASE	A90401983	P.O.R.
nXR60i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		EDWARDS nXR60I MULTI STAGE ROOTS DRY PUMP, KF40 INLET FLANGE, 60 M^3/HR, 100-127/200-240V, 50/60 HZ, 1-PHASE	A90502983	P.O.R.
nXR90i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		EDWARDS nXR90I MULTI STAGE ROOTS DRY PUMP, KF40 INLET FLANGE, 90 M^3/HR, 100-127/200-240V, 50/60 HZ, 1-PHASE	A90602983	P.O.R.
nXR120i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		EDWARDS nXR120I MULTI STAGE ROOTS DRY PUMP, KF40 INLET FLANGE, 120 M^3/HR, 100-127/200-240V, 50/60 HZ, 1-PHASE	A90702983	P.O.R.

X CLOSE

Can't Find The Pump You're Looking For?

Let our new Pump Selection Guide help! With over 450 vacuum pumps to choose from, the KJLC^® Vacuum Pump Selection Guide is designed to help you find one that meets your vacuum requirements. You can narrow down our pump offering by simply choosing from a list of different search criteria. For more information please contact us by clicking here .

Accessories Table

Description	For Pump Model(s)	Accessory Type	Part Number	Price	In Stock	Add To Cart
Description	For Pump Model(s)	Accessory Type	Part Number	Price	In Stock	Add To Cart
2m electrical supply cable, China	All nXRi Series Pumps	Power Cable	A50509003	P.O.R.
2m electrical supply cable, Europe	All nXRi Series Pumps	Power Cable	A50506003	P.O.R.
2m electrical supply cable, NEMA 5-15P, North America/Japan (100-120 V)	All nXRi Series Pumps	Power Cable	A50507003	P.O.R.
2m electrical supply cable, NEMA 6-15P, North America (200-240 V)	All nXRi Series Pumps	Power Cable	A50507006	P.O.R.
2m electrical supply cable, UK, three pin plug	All nXRi Series Pumps	Power Cable	A50505003	P.O.R.
Floor/cart mounting kit	All nXRi Series Pumps	Interconnect Cable	A90590000	P.O.R.
Gas ballast adaptor for inert gas (1/4" quick connect)	All nXRi Series Pumps	Power Cable	A73501811	P.O.R.
Gas ballast blank plug	All nXRi Series Pumps	Power Cable	A73501806	P.O.R.
