Edwards EM Series (Large) Edwards EM Series (Large) 1 Edwards EM Series (Large) 2 Edwards EM Series (Large) 3

Edwards EM Series (Large)

The E2M Two Stage Oil Sealed Rotary Vane Pump is the tried and tested solution for applications when better ultimate vacuum down to 10-3 mbar is needed. Available in sizes from 40 to 275 m3h-1 it features a robust design for reliable and stable high vacuum performance.

Features

  • Reliability: Reliable and stable process - effective lubrication even under high gas loads
  • Robust: No contamination of process - oil and air suck-back protection
  • Performance: Long and trouble free life - industrial roller bearings on drive shaft

Applications

  • Furnaces and metallurgy
  • Optical and display coating
  • Pharmaceutical freeze drying
  • Refrigeration and air conditioning system evacuation
  • Transformer and cable drying
  • Brake line evacuation
  • Industrial leak detection
  • Plasma Coating and Cleaning

Positive Pressure Oil Lubrication:

These pumps have a well-proven, positive pressure oil lubrication system developed by Edwards to ensure correct lubrication in all operating modes, particularly under high gas loads where oil starvation is a common problem with other pumps.

  • Integral oil pump ensures an adequate oil flow through the stator/rotor assembly at all times
  • Only clean degassed oil is supplied to the high vacuum stage on two stage pumps
  • System is much less dependent on correct oil levels in the reservoir than other pump designs
  • Pumps can operate with oil levels as low as 50–70% of the maximum fill level (NOT RECOMMENDED)

Dimensional Drawings


BOCEd E2M40 BOCEd E2M80 BOCEd E2M175 BOCEd E2M275

Charts


Specifications Table

Pump Model E2M40 E2M80 E2M175 E2M275
Pumping Speeds
50 (Hz)
21.8 CFM
616 L/min
10.3 L/s
37.0 m3/hr
60 (Hz)
25.9 CFM
733 L/min
12.2 L/s
44.0 m3/hr
50 (Hz)
47.1 CFM
1333 L/min
22.1 L/s
80.0 m3/hr
60 (Hz)
56.5 CFM
1599 L/min
26.6 L/s
96.0 m3/hr
50 (Hz)
104 CFM
2965 L/min
49.2 L/s
178 m3/hr
60 (Hz)
126 CFM
3567 L/min
59.2 L/s
214 m3/hr
50 (Hz)
171 CFM
4865 L/min
80.8 L/s
292 m3/hr
60 (Hz)
206 CFM
5833 L/min
96.8 L/s
349 m3/hr
Max Water Vapor
Pumping Rate
(with gas ballast)
200 g/hr 300 g/hr 2400 g/hr 2500 g/hr
Ultimate Pressure
Partial With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.80 x 10-3 Torr
Partial Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Total With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.75 x 10-3 Torr
Total Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Partial With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.80 x 10-3 Torr
Partial Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Total With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.75 x 10-3 Torr
Total Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Partial With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.80 x 10-3 Torr
Partial Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Total With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.75 x 10-3 Torr
Total Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Partial With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.80 x 10-3 Torr
Partial Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Total With Gas Ballast
5.00 x 10-3 hPA
5.00 x 10-3 mbar
5.00 x 10-1 Pa
3.75 x 10-3 Torr
Total Without Gas Ballast
1.00 x 10-3 hPA
1.00 x 10-3 mbar
1.00 x 10-1 Pa
7.50 x 10-4 Torr
Cooling Method(s) Method
Convection
Method
Convection
Method
Convection
Method
Convection
Motor Power HP (kW) 2.01 ( 1.50 ) 4.02 ( 3.00 ) 8.72 ( 6.50 ) 11.5 ( 8.55 )
Inlet Flange ISO40-F
ISO40-F
ISO63-F
ISO63-F
Exhaust Flange 25mm NPT
25mm NPT
ISO40
KF40
KF40
Oil Type(s) Hydrocarbon Oil
Part: KJLSS19G1
Hydrocarbon Oil
Part: KJLSS19G1
Hydrocarbon Oil
Part: KJLSS19G5
Hydrocarbon Oil
Part: KJLSS19G5
Oil Capacity Quarts (Liters)
*Unless otherwise noted
3.15 ( 3.00 ) 3.15 ( 3.00 ) 21.0 ( 20.0 ) 24.2 ( 23.0 )
Noise db(A) 65.0 70.0 75.0 75.0
Compression Stages 2
2
2
2
Series Standard
Standard
Standard
Standard
Weight Lbs (kg) 165 ( 75.0 ) 224 ( 102 ) 449 ( 204 ) 488 ( 222 )
Dimensions in. (mm.) 26.2 x 9.45 x 15.6
(665 x 240 x 397 )
31.3 x 10.5 x 16.9
(795 x 266 x 430 )
36.9 x 15.9 x 20.9
(938 x 404 x 532 )
43.0 x 15.9 x 20.9
(1091 x 404 x 532 )
Lubrication Type Wet
Wet
Wet
Wet
Technology Type Rotary Vane
Rotary Vane
Rotary Vane
Rotary Vane
X CLOSE
Product Brochure
For a download of the Edwards Oil Sealed Vacuum Pump & Booster Solutions for Industrial Processes Brochure, click here.
Vacuum Pump Repair
& Services
World class service center for scheduled maintenance, evaluation, and vacuum pump repair.
Request a Service Quote
Request a Pump RMA
Remanufactured Vacuum
Pumps
Click here to view a list of remanufactured vacuum pumps available from The KJLC's Remanufactured Vacuum Pump Division.
Pumps FAQ
Click here for answers to some of the most common questions we are asked.
Contact Us
Contact Us
To contact someone directly, please click here, or call +1 412 387 9200 to get in contact with your dedicated sales team.
Notes:
  • ATEX versions available; please call or visit our website for more information.
  • One charge of hydrocarbon oil will be provided with each pump.
  • PFPE prepared and Azide resistant models are available.

Got VacuCADSM?
VacuCAD is a free library containing thousands of 2D CAD drawings (in DXF format) and 3D Models (in STP format) for many of our standard vacuum components and chambers. Please Log in

Ordering Table

(Click column headers to sort data)

X CLOSE
Pump Model Inlet Flange Voltage & Phases Oil Prep Manual Reman KJLC Remanufactured Description Part Number Price In Stock Add To Cart Accessories
Pump Model Inlet Flange Voltage & Phases Oil Prep Manual Reman KJLC Remanufactured Description Part Number Price In Stock Add To Cart Accessories
E2M40 ISO40-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø Download PDF PUMP, MECH, E2M40, ISO40 INLET, 25MM FLANGE SUITABLE FOR NW25, 380-400V 50HZ, 230/460V 60HZ A36404940 P.O.R. Contact KJLC for Availability
E2M80 ISO40-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø KJLC Remanufactured PUMP,REMANUFACTURED, MECH,E2M80,56CFM,INERT PREP, 208-230/460V,50/60HZ,3PH NIB....New in Box SN# A36502982-R P.O.R. In Stock
E2M80 ISO40-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø Download PDF PUMP, MECH, E2M80, HC IE3 EU/US 380-400V 50 HZ, 230/460 60 HZ A36504940 P.O.R. Contact KJLC for Availability
E2M175 ISO63-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø Hydrocarbon oil Download PDF KJLC Remanufactured PUMP,MECH,E2M175,230/460VAC, 60HZ,3 PHASE,126 CFM, REMANUFACTURED A36603982-R P.O.R. In Stock
E2M175 ISO63-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø Download PDF PUMP, MECH, E2M175, HC IE3 EU/US 50/60HZ, 380-400V 50HZ, 230/460V 60HZ, INLET CONNECTION: ISO63, OUTLET CONNECTION: ISO40 A36604940 P.O.R. Contact KJLC for Availability
E2M275 ISO63-F 380/400 VAC, 50 Hz, 230/460 VAC 60 Hz, 3-Ø Download PDF PUMP, MECH, E2M275, HC IE3 EU/US 50/60HZ, 380-400V 50HZ, 230/460V 60HZ, INLET CONNECTION: ISO63, OUTLET CONNECTION: ISO40 A36704940 P.O.R. Contact KJLC for Availability
CloseX
X CLOSE
Can't Find The Pump You're Looking For? Let our new Pump Selection Guide help! With over 450 vacuum pumps to choose from, the KJLC® Vacuum Pump Selection Guide is designed to help you find one that meets your vacuum requirements. You can narrow down our pump offering by simply choosing from a list of different search criteria. For more information please contact us by clicking here .

Accessories Table

For Pump Model(s) Description Part Number Price In Stock Add To Cart
For Pump Model(s) Description Part Number Price In Stock Add To Cart
All EM Series
Pumps
Bolted NW40 to NW40KF Adapter
ED-A1516
P.O.R.
Contact KJLC for Availability
All EM Series
Pumps
Bolted NW50 to NW50KF Adapter
C10005080
P.O.R.
Contact KJLC for Availability
All EM Series
Pumps
Clamp for KF40 Flange
QF40-150-C
P.O.R.
In Stock
All EM Series
Pumps
Clamp for KF50 Flange
QF50-200-C
P.O.R.
In Stock
E2M40, E2M80 Clamping Kit, For QF40 Flange, Including Aluminum Clamp and FKM Centering Ring
QF40-HDKIT
P.O.R.
Contact KJLC for Availability
All EM Series
Pumps
Fluorocarbon Centering Ring
for KF40 Flange
QF40-150-SRV
$13.10
In Stock
All EM Series
Pumps
Fluorocarbon Centering Ring
for KF50 Flange
QF50-200-SRV
$15.10
In Stock
All EM Series
Pumps
KJLSS 19 Oil (1 gallon)
KJLSS19G1
$45.00
In Stock
All EM Series
Pumps
KJLSS 19 Oil (1 quart)
KJLSS19Q1
$17.00
In Stock
E1M40
E1M80
E2M80
Oil Mist Eliminator
A46203000
P.O.R.
Contact KJLC for Availability
E2M175
E1M175
E2M275
E1M275
Oil Mist Eliminator
A46204000
P.O.R.
Contact KJLC for Availability
E1M40 Repair Kit
A36301131
P.O.R.
Contact KJLC for Availability
E1M80
E2M80
Repair Kit
A34501131
P.O.R.
Contact KJLC for Availability
E2M40 Repair Kit
A34401131
P.O.R.
Contact KJLC for Availability
E1M40 Replacement Blade (Vane) Kit
ED-A34401050
P.O.R.
Contact KJLC for Availability
E1M80 Replacement Blade (Vane) Kit
A34501050
P.O.R.
Contact KJLC for Availability
E2M40 Replacement Blade (Vane) Kit
A36401050
P.O.R.
Contact KJLC for Availability
E2M80 Replacement Blade (Vane) Kit
A36501050
P.O.R.
Contact KJLC for Availability
