Dosing valve are used in application where a reduced conductance and high repeatability is requested.
Dosing Valve (Series 211)

Specifications Table
Series Number | 211 |
Series Name | Dosing Valve |
Description | For introducing a controlled, reproducible flow of gas into a vacuum chamber. |
Actuator Types | Manual actuator (hand wheel) |
Sealing Gate | FKM (VITON®) |
Sealing Bonnet | FKM (VITON®) |
Feedthrough | Shaft feedthrough |
Leak Rate - Body | < 1 . 10-9 mbar ls-1 |
Leak Rate - Seat | < 1 . 10-9 mbar ls-1 |
Nominal inside diameters (ID) in mm (inches) | 10 (3/8") - 16 (5/8") |
Body material | Aluminum; Stainless steel |
Dimensional Drawings
