Unit Price:
KJLC will contact you

The electrical and thermal ratings specified are of safe operating limits determined by various factors including material properties, mechanical design, and the intended operating environment. All electrical ratings are based on operation with one side in dry atmosphere and the other side in vacuum of less than 1 x 10-4 Torr. All VacuCAD files as well as any dimensions shown or listed in our ordering tables do not include manufacturing tolerances and are provided for reference only.
Product VacuCAD Files
Product VacuCAD Files


STP (Please Log In)
DXF (Please Log In)
Contact Us
Contact Us
To contact someone directly, please click here, or call +1 412 387 9200 to get in contact with your dedicated sales team.


Type : Male
Contact Type: Crimp
Service : Vacuum
Material : Gold Plated Copper Alloy, SST Outer
Accepts Wire Size: 0.010 to 0.039
Accepts Wire Size (Metric): 0.25 to 1
Thermal Range (°C): -269 to 300
Per Pkg: 10
Crimp Tool: M22520/1-01
Turret : TP585
Insertion Tool: M81969/1-02
Removal Tool: M81969/1-02

Dimensional Drawings
Contact Us - FTADPEEKM-10 -
